Heavy-Duty Pallet Handlers – Electric Transport of Pallets up to 50 Tonnes

Move your machine parts, tooling, heavy goods and cargo efficiently with Elof Pallet Handlers. With capacities from 7 to 50 tonnes, these electric driven transporters feature fixed, manually or automatically adjustable forks, minimal floor pressure thanks to non-counterweight design, and flexible driver positions. Perfect for tight spaces, high loads and clean, emission-free operations.

Key Features

Max Load: 7, 15, 30, or 50 tonnes depending on model
Power / Battery: 80 V, 250 Ah for lower load models; 80 V, 375 Ah for mid; 80 V, 625 Ah for 50 t models
Fork configuration: Fixed, manually adjustable, automatically adjustable forks
Driver positions: STB, SIB, SIT (for 50 t)
Use case environment: Indoor transport, production floor, warehouse, storage, tooling & machine parts

Why Elof Pallet Handlers?

Load range 10-50 tonnes, so you can select the model that matches your load needs.
Non-counterweight / low lift design reduces handler weight and floor impact.
Electric drive: no exhaust emissions, quiet, lower maintenance.
Fork options: fixed forks, manually adjustable forks, automatically adjustable forks.
Multiple driver position configurations: STB (standing behind), SIB (sitting behind), and SIT (sitting high) in the largest models.

Model Overview Pallet handlers

model	max load	power battery	fork type	driver position	driver position label
P10110	10 t	80 V, 250 Ah	Fixed	STB	Standing behind the drive unit
P10120	10 t	80 V, 250 Ah	Fixed	SIB	Sitting behind the drive unit
P15110	15 t	80 V, 250 Ah	Adjustable	STB	Standing behind the drive unit
P15120	15 t	80 V, 250 Ah	Adjustable	SIB	Sitting behind the drive unit
P20150	20 t	80 V, 250 Ah	Fixed	SIB	Sitting behind the drive unit
P30310	30 t	80 V, 660 Ah	Fixed	STB	Standing behind the drive unit
P30320	30 t	80 V, 660 Ah	Fixed	SIB	Sitting behind the drive unit
P30330	30 t	80 V, 660 Ah	Fixed	SIT	Sitting on high drive unit
P50310	50 t	80 V, 660 Ah	Fixed	STB	Standing behind the drive unit
P50320	50 t	80 V, 660 Ah	Fixed	SIB	Sitting behind the drive unit
P50330	50 t	80 V, 660 Ah	Fixed	SIT	Sitting on high drive unit

STB = Standing behind the drive unit, SIB = Sitting behind the drive unit, SIT = Sitting on high drive unit

Benefits for Your Business

Lower floor wear and costs via light, compact non-counterweight design.
High load capacity up to 50 tonnes with electric, emission-free operation.
Flexible for different pallets & carriers through adjustable forks.
Operator comfort & safety via different driver positions.
Higher throughput & reliability in demanding indoor transport applications.

Applications

Production floors & factories where heavy tooling, machine parts or cargo must be moved efficiently.
Warehouse and storage operations needing heavy pallet movements.
Environments with tight pathways / narrow aisles where compact dimensions are demanded.
Wherever floor protection matters – low pressure machines reduce damage and maintenance.

About Elof Handler

For more than 20 years, Elof Handler has been developing patented indoor transport technology that makes heavy load handling easier, safer, and more sustainable. Our Swedish-engineered machines are used worldwide by leading industrial companies that demand reliability and performance.

Choose Your Pallet Handler & Get a Quote

Need a machine that matches your load, space and safety requirements?
